Key Advantages:
Equipped with an intelligent touchscreen control panel and PLC centralized control system. High-quality AC contactors and independent digital temperature controllers allow precise temperature adjustment for stable sealing performance.
The whole machine is manufactured with full SUS304 stainless steel and heavy-duty aluminum structure. All molds are made of anodized aluminum alloy, offering excellent corrosion resistance, easy cleaning, and long service life.
Compact tabletop design saves workspace and is suitable for supermarkets, fresh food shops, and food processing applications. Compatible with both printed film (eye-mark film) and plain sealing film.
|
Type |
Electric Desktop MAP Tray Sealer Machine |
|
Model |
DF-300TQ |
|
Maximum Width of Roll Film (mm) |
245 |
|
Maximum Diameter of Roll Film (mm) |
180 |
|
Gas Replacement Rate |
99% |
|
Packaging Speed |
7–8 |
|
Production Capacity (boxes/hour) Output 1 |
≈480 |
|
Production Capacity (boxes/hour) Output 2 |
≈800 |
|
Power Supply (V/Hz) |
220/50 |
|
Total Power (kW) |
1.3 |
|
Equipment Weight (kg) |
50 |
|
Equipment Dimensions L×W×H (mm) |
500×530×680 |
|
Conversion of Packaging Gross Weight and Volume (kg) |
63 |
|
Packaging Box Dimensions L×W×H (mm) |
600×630×780 |
|
Maximum Tray Size (mm) Output 1 |
310×200×80 (×1) |
|
Maximum Tray Size (mm) Output 2 |
200×140×80 (×2) |
|
Actual Gross Weight (kg) |
70 |
Configuration List
|
No. |
Name and Application |
Brand |
|
1 |
Relay Group |
Omron |
|
2 |
PLC Power Supply |
Mean Well (Taiwan) |
|
3 |
Box Pushing Cylinder |
AirTAC |
|
4 |
PLC |
Gumei (Shenzhen) |
|
5 |
Touch Screen |
Gumei (Shenzhen) |
|
6 |
Damping Motor |
Taisong |
|
7 |
Push Button |
Schneider (France) |
